Optical Class – Approved
Viewing Area – 107 x 75 mm (4.21″ x 2.95″)
Cartridge Size – 156 x 123 x 33 mm (6.14″ x 4.84″ x 1.30″)
Arc Sensor – 4
Light State – DIN 3
Grind State – DIN 3
Cutting Shade – Shade No. from 5 to 8
Welding Shade – Shade No. from 9 to 13
Shade Control – Internal, Digital Display Control
Power On / Off – Automatic On / Off
Sensitivity Control – Low ~ High, Digital Display Control
UV/IR Protection – Up to Shade DIN13 at all times
Power Supply – Solar cell. Battery replaceable, 2 x CR2450 lithium battery
Switching Time – 1/25,000 s. from Light to Dark at 55 °C (131 °F)
Grinding – Yes
Delay (Dark to Light) – 0.1 ~ 1.0 s, Digital Display Control
Low Amperage TIG Rated – ≥ 2 amps (DC); ≥ 2 amps (AC)
Operating Temp. – -5 °C ~ +55 °C (23 °F ~ 131 °F)
Storing Temp. – -20 °C ~ +70 °C (-4 °F ~ 158 °F)
Helmet Material – High Impact Resistance Nylon
Total Weight – 778 g
Application Range – Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding
Approved – CE, EN ISO 16321-1 :2022, EN ISO 16321-2:2021, EN 175, EN 166 ANSI Z87.l, Z94.3, AS/NZS 1338.l
