Product Description
Technical Data
Input Voltage AC 400V – 50/60 Hz
Ieff(A) 13.2
Input Power (kVA) 15
Voltage Adjustment Range (V) 15 – 36
Current Range (A) MIG 50 – 350 MMA 20 – 350
Duty Cycle @ 40°C 350A @ 40%
No-Load Voltage (V) 65
Wire Speed (m/min) 1 – 16
Efficiency (%) 85
Power Factor 0.93
Protection/Insulation Class IP21S/F
Dimensions (LxWxH mm) 1020 x 505 x 1460
Weight (Kg) 104
